ADLINK
ADLINK Technology Inc. (TAIEX:6166) leads edge computing, the catalyst for a world powered by artificial intelligence. ADLINK manufactures edge hardware and develops edge software for embedded, distributed and intelligent computing - from powering medical PCs in the intensive care unit to building the world’s first high-speed autonomous race car - more than 1600 customers around the world trust ADLINK for mission-critical success. Headquartered in Taiwan, ADLINK has operations in the United States, UK, Singapore, Beijing, Shanghai, Shenzhen, Japan, Korea and Germany. ADLINK products are currently available in over 40 countries across five continents, with worldwide distribution networks and more than 1,800 employees. ADLINK is proud to be associated with many major technology leaders and Fortune 500 companies. With design and technology centers in the U.S., the Pacific Rim regions and Germany, ADLINK is a technology-leading platform provider in the embedded computing industry.
RQX-59 Series
Introducing the revolutionary ROScube-X RQX-59 Series, a state-of-the-art ROS 2 robotic controller powered by the incomparable NVIDIA® Jetson AGX Orin™ module. The RQX-59 Series ensures seamless integration into robotic and autonomous driving applications, thanks to its integrated powerhouse NVIDIA CUDA® GPU and dual deep learning accelerators. Additionally, it offers a wide range of interfaces, including GMSL1/2 or FPD-Link III cameras. Get ready to redefine the boundaries of robotic possibilities with the RQX-59 Series, the epitome of efficiency and innovation.
Learn more about RQX-59 Series
oToBrite GSML/FPD-Link Camera Modules
oToBrite’s automotive GSML/FPD-Link camera modules, including the 2MP oToCAM222 series (Sony ISX021), oToCAM264ISP series (Sony IMX390), 3MP oToCAM223 series (Sony ISX031) and 5MP oToCAM260ISPseries (Sony IMX490), are fully integrated with ADLINK's RQX-59 Series. The camera modules are listed as below.
Model | Resolution | Sensor Type | View Angle | Output Format |
---|---|---|---|---|
oToCAM264ISP-H61M | 2MP / 3MP | IMX390CQV | 63.9° | GMSL2 |
oToCAM264ISP-N73M | 2MP / 3MP | IMX390CQV | 73° | GMSL2 |
oToCAM264ISP-C120M | 2MP / 3MP | IMX390CQV | 120.6° | GMSL2 |
oToCAM264ISP-N186M | 2MP / 3MP | IMX390CQV | 186° | GMSL2 |
oToCAM264ISP-H61T | 2MP / 3MP | IMX390CQV | 63.9° | FPD-Link III |
oToCAM264ISP-N73T | 2MP / 3MP | IMX390CQV | 73° | FPD-Link III |
oToCAM264ISP-C103T | 2MP / 3MP | IMX390CQV | 103° | FPD-Link III |
oToCAM264ISP-C120T | 2MP / 3MP | IMX390CQV | 120.6° | FPD-Link III |
oToCAM264ISP-N186T | 2MP / 3MP | IMX390CQV | 186° | FPD-Link III |
oToCAM222-H61M | 2MP / 3MP | ISX021 | 64° | GMSL2 |
oToCAM222-C120M | 2MP / 3MP | ISX021 | 120.6° | GMSL2 |
oToCAM222-S195M | 2MP / 3MP | ISX021 | 195.9° | GMSL2 |
oToCAM222-H61T | 2MP / 3MP | ISX021 | 64° | FPD-Link III |
oToCAM222-C103T | 2MP / 3MP | ISX021 | 103° | FPD-Link III |
oToCAM222-C120T | 2MP / 3MP | ISX021 | 120.6° | FPD-Link III |
oToCAM222-S195T | 2MP / 3MP | ISX021 | 195.9° | FPD-Link III |
oToCAM223-H61M | 2MP / 3MP | ISX031 | 63.9° | GMSL2 |
oToCAM223-C120M | 2MP / 3MP | ISX031 | 120.6° | GMSL2 |
oToCAM223-S195M | 2MP / 3MP | ISX031 | 195.9° | GMSL2 |
oToCAM260ISP-C30M | 5MP | IMX490 | 30° | GMSL2 |
oToCAM260ISP-C62M | 5MP | IMX490 | 62.5° | GMSL2 |
oToCAM260ISP-C120M | 5MP | IMX490 | 120° | GMSL2 |
Advantech
Advantech’s corporate vision is to enable an intelligent planet. The company is a global leader in the fields of IoT intelligent systems and embedded platforms. To embrace the trends of IoT, big data, and artificial intelligence, Advantech promotes IoT hardware and software solutions with the Edge Intelligence WISE-PaaS core to assist business partners and clients in connecting their industrial chains. Advantech is also working with business partners to co-create business ecosystems that accelerate the goal of industrial intelligence.
AFE-R360
The AFE-R360, featuring a 3.5" SBC, supports up to 8 MIPI-CSI lanes for low-latency camera inputs, alongside 3 LAN and 3 USB-C ports to accommodate depth and LiDAR sensors. Powered by Intel's ® Core™ Ultra 16-core processor, Arc™ graphics GPU, and the industry's first processor with an integrated NPU delivering up to 32 TOPs of performance, this platform is further enhanced with the OpenVINO™ toolkit, optimizing AI tasks.
Learn more about AFE-R360
oToBrite GMSL Camera Modules
oToBrite’s automotive GMSL camera oToCAM222 series, equipped with the Sony ISX021 sensor, offers 2.5M high-resolution pixels and flexible viewing angles ( 64°/ 120.6°/ 195.9° ), making it an ideal solution for diverse AMR scenarios.
Model | Resolution | Sensor Type | View Angle | Output Format |
---|---|---|---|---|
oToCAM222-H61M | 2MP / 3MP | ISX021 | 64° | GMSL2 |
oToCAM222-C120M | 2MP / 3MP | ISX021 | 120.6° | GMSL2 |
oToCAM222-S195M | 2MP / 3MP | ISX021 | 195.9° | GMSL2 |
AVerMedia
AVerMedia, a proud Taiwanese brand, leverages its expertise in research, development, and manufacturing to create cutting-edge video solutions for consumers and businesses alike. Our products cater to the needs of streamers, content creators, and professionals seeking efficient remote communication tools. We're also at the forefront of AI integration, both by incorporating AI into our existing products and developing new AI-focused solutions. Stay Ahead with AVerCooler – Achieving 5°C Lower Operation under Others’ Regular Workload for Enhanced NVIDIA Jetson Efficiency, Extended Lifespan, and Superior Performance.
Box PC - D135
AVerMedia’s AI Box PC D135 equips powerful NVIDIA® Jetson Orin NX module. This efficient system-on-module (SoM) opens new worlds of embedded IoT applications with full analytic capabilities. D135 BOX PC is designed for the IP65 (IP67 by request) and features a rich assortment of waterproof I/O ports for rapid AI-based solution development and seamless deployment as required by demanding applications. AVerMedia supports businesses of all sizes and offers customizable BSP services, flexible MoQ, in addition to NVIDIA’s JetPackTM SDK.
Learn more about Box PC - D135
oToBrite GMSL Camera Modules
oToBrite's automotive-grade GMSL camera modules, including the oToCAM222 with Sony 2.5M ISX021 sensor and the oToCAM223 series with Sony 3M ISX031 sensor, are now fully integrated with AVerMedia's Box PC – D135, featuring the NVIDIA® Jetson Orin NX/Orin Nano module. The collaboration brings unmatched durability and performance, with both oToBrite’s IP67/69K automotive camera modules and AVerMedia’s IP65/IP67 Box-PC passing stringent tests for vibration, wide temperature ranges, and IP-rated dust and water resistance. Together, we’re setting new standards for reliability and precision in AMR systems.
Model | Resolution | Sensor Type | View Angle | Output Format |
---|---|---|---|---|
oToCAM222-H61M | 2MP / 3MP | ISX021 | 64° | GMSL2 |
oToCAM222-C120M | 2MP / 3MP | ISX021 | 120.6° | GMSL2 |
oToCAM222-S195M | 2MP / 3MP | ISX021 | 195.9° | GMSL2 |
oToCAM223-H61M | 2MP / 3MP | ISX031 | 63.9° | GMSL2 |
oToCAM223-C120M | 2MP / 3MP | ISX031 | 120.6° | GMSL2 |
oToCAM223-S195M | 2MP / 3MP | ISX031 | 195.9° | GMSL2 |
Neousys
Established in 2010, Neousys Technology designs, manufactures, and markets innovative edge AI computing platforms and rugged embedded computers. Neousys specializes in the thermal management and integration of high-computation-power CPUs and GPUs. Its proficiency in specialized I/O connectivity allows us to utilize various cameras and sensors to meet diverse application needs. Committed to lead the future of automation and intelligentization across industries, Neousys Technology stands out with high-performance and application-oriented product designs to lay the foundation for an intelligent, connected world, and advancing edge AI.
- Neousys Website
- Contact Neousys:sales@neousys-tech.com
NRU-160-AWP Series
The NRU-160-AWP series is a rugged, IP66 waterproof edge AI computer driven by an NVIDIA® Jetson Orin™ NX or Orin™ Nano. Its target applications include smart city roadside installations, AI inspection in food factories, perception units for outdoor robots, and ADAS for off-highway vehicles. Furthermore, it aims to redefine rugged, wide-temperature edge AI with its waterproof features at an affordable cost, achieved through a streamlined mechanical design, carefully selected waterproof connectors and standardized cable kit.
Learn more about NRU-160-AWP Series
oToBrite GMSL Camera Modules
oToBrite’s automotive GSML camera modules, including the 2MP oToCAM264ISP series (Sony IMX390), 3MP oToCAM223 series (Sony ISX031) and 5MP oToCAM260ISP series (Sony IMX490), are fully integrated with Neousys's NRU-160-AWP Series. The camera modules are listed as below.
Model | Resolution | Sensor Type | View Angle | Output Format |
---|---|---|---|---|
oToCAM264ISP-H61M | 2MP / 3MP | IMX390CQV | 63.9° | GMSL2 |
oToCAM264ISP-N73M | 2MP / 3MP | IMX390CQV | 73° | GMSL2 |
oToCAM264ISP-C120M | 2MP / 3MP | IMX390CQV | 120.6° | GMSL2 |
oToCAM264ISP-N186M | 2MP / 3MP | IMX390CQV | 186° | GMSL2 |
oToCAM223-H61M | 2MP / 3MP | ISX031 | 63.9° | GMSL2 |
oToCAM223-C120M | 2MP / 3MP | ISX031 | 120.6° | GMSL2 |
oToCAM223-S195M | 2MP / 3MP | ISX031 | 195.9° | GMSL2 |
oToCAM260ISP-C30M | 5MP | IMX490 | 30° | GMSL2 |
oToCAM260ISP-C62M | 5MP | IMX490 | 62.5° | GMSL2 |
oToCAM260ISP-C120M | 5MP | IMX490 | 120° | GMSL2 |
Vecow
Vecow is a team of global embedded experts. We are dedicated to designing, developing, producing, and selling industrial-grade computer products. All of our products are leading in performance, trusted in reliability, exhibit advanced technology, and innovative concepts. Vecow offers AI-ready Inference Systems, AI Computing Systems, Fanless Embedded Systems, Vehicle Computing Systems, Robust Computing Systems, Single Board Computers, Multi-Touch Computers, Multi-Touch Displays, Frame Grabbers, Embedded Peripherals and Design & Manufacturing Services with leading performance, trusted reliability, advanced technology, and innovative concept.
- Vecow Website
- Contact Vecow : sales@vecow.com
Vecow EAC-5000 Series
Vecow EAC-5000 Series is powered by NVIDIA Jetson AGX Orin platform that features an Arm® Cortex®-A78AE CPU delivering up to 275 TOPS of AI performance and integrates an advanced NVIDIA Ampere architecture GPU with 64 Tensor Cores. It’s capable of delivering server-class performance for edge AI applications. The EAC-5000 Series is rugged in design and supports high compute density with I/O flexibility, including 8 GMSL2 cameras, 1 PCIe x8 slot, 2 GigE LAN with an optional choice of X-coded M12 connector, 5 USB, 2 COM, 2 Isolated CAN Bus, and 2 SIM card sockets.
Learn more about Vecow EAC-5000
oToBrite GMSL Camera Modules
oToBrite’s automotive GMSL camera modules, including the 2MP oToCAM222 series (Sony ISX021), oToCAM264 series (Sony IMX390), and 5MP oToCAM260/261/262 series (Sony IMX490), are fully integrated with Vecow’s fanless EAC-5000 platform powered by NVIDIA® Jetson AGX Orin™ delivering up to 275 TOPS of AI performance. The camera modules are listed as below.
Model | Resolution | Sensor Type | View Angle | Output Format |
---|---|---|---|---|
oToCAM264ISP-H61M | 2MP / 3MP | IMX390CQV | 63.9° | GMSL2 |
oToCAM264ISP-N73M | 2MP / 3MP | IMX390CQV | 73° | GMSL2 |
oToCAM264ISP-C120M | 2MP / 3MP | IMX390CQV | 120.6° | GMSL2 |
oToCAM264ISP-N186M | 2MP / 3MP | IMX390CQV | 186° | GMSL2 |
oToCAM222-H61M | 2MP / 3MP | ISX021 | 64° | GMSL2 |
oToCAM222-C120M | 2MP / 3MP | ISX021 | 120.6° | GMSL2 |
oToCAM222-S195M | 2MP / 3MP | ISX021 | 195.9° | GMSL2 |
oToCAM223-H61M | 2MP / 3MP | ISX031 | 63.9° | GMSL2 |
oToCAM223-C120M | 2MP / 3MP | ISX031 | 120.6° | GMSL2 |
oToCAM223-S195M | 2MP / 3MP | ISX031 | 195.9° | GMSL2 |
oToCAM260ISP-C30M | 5MP | IMX490 | 30° | GMSL2 |
oToCAM260ISP-C62M | 5MP | IMX490 | 62.5° | GMSL2 |
oToCAM260ISP-C120M | 5MP | IMX490 | 120° | GMSL2 |
